Steam Trap

• Application
• Steam, condensate, air, non-condensable gas

• Connection Type
• Threaded / Flanged / Welded

• Disc
• SUS440C, Stellite alloy

• Features
• Automatic condensate/air discharge, steam leakage prevention, efficient heat transfer, water hammer prevention, energy saving

• Material
• Gray Cast Iron (HT200/HT250): PN16, 220 , for general non-corrosive service Ductile Iron (FCD450): PN25, 350 , higher strength than cast iron Cast Steel (WCB/A105): PN40 PN100, 450 , for medium and high pressure Stainless Steel (304/316L): PN40, 550 , corrosion resistant, for food and pharmaceutical

• Media
• Water, Oil, Gas, Base, Acid, Other

• Port Size
• Standard range: DN15~DN100 (1/2"~4"); Common sizes: DN15, DN20, DN25, DN32, DN40, DN50

• Product Type
• Steam Trap

• Sealing
• Metal hard seal (Stellite, cemented carbide); Soft seal (PTFE, fluororubber)

• Size
• Standard range: DN15 DN100 (1/2 4 )Common sizes: DN15, DN20, DN25, DN32, DN40, DN50

• Structure
• Other

• Temperature
• Cast iron: 220 ; Cast steel: 450 ; Stainless steel: 550 Celsius (oC)

• Type
• Steam Trap / Condensate Drain Trap

• Usage
• Steam Trap Product Introduction & Technical Specifications 1. Product Overview A steam trap, also known as a steam separator, is a critical automatic valve in steam systems. It automatically discharges condensate, air and non-condensable gases while effectively preventing steam leakage. Its core functions include ensuring efficient heat transfer of steam equipment, preventing pipeline water hammer, avoiding equipment corrosion, and saving steam energy. It is widely used in all industrial and civil fields that use steam, such as petrochemical, power, food, textile, and HVAC industries. 2. Technical Specifications 2.1 Nominal Diameter (DN) Standard range: DN15 ~ DN100 (1/2" ~ 4") Common sizes: DN15, DN20, DN25, DN32, DN40, DN50 2.2 Nominal Pressure (PN/Class) GB standard: PN16, PN25, PN40, PN63, PN100 ASME standard: Class 150, Class 300, Class 600 High-pressure type: Up to 42 MPa (special for power stations) 2.3 Working Temperature Cast iron: 220 Cast steel: 450 Stainless steel: 550 2.4 Discharge Capacity Small: 50 ~ 500 kg/h Medium: 1 ~ 10 t/h Large: 10 ~ 100 t/h 3. Main Component Materials 3.1 Body Materials Gray cast iron (HT200/HT250): Suitable for PN16, 220 , and general non-corrosive environments. Ductile iron (FCD450): Suitable for PN25, 350 , with higher strength than ordinary cast iron. Cast steel (WCB/A105): Suitable for PN40 ~ PN100, 450 , medium and high pressure conditions. Stainless steel (304/316L): Suitable for PN40, 550 , corrosion-resistant, and meets food/pharmaceutical grade requirements. Chromium-molybdenum steel (15CrMo/12Cr1MoV): Designed for high temperature and high pressure scenarios, especially for power station boilers. 3.2 Internal Component Materials Float ball: 304/316 stainless steel Seat / disc: SUS440C, Stellite alloy (hardness HRC60) Bimetallic strip: Nickel-iron alloy, manganese-copper alloy composite layer Bellows: 316L, Hastelloy alloy 3.3 Sealing Materials Hard seal: Stellite overlay, hard alloy (for high temperature and high pressure conditions) Soft seal: PTFE, fluororubber ( 200 , low leakage)
